FHP Galletti: the high-performance ductable fan coil for versatile installations

Galletti expands its range of hydronic terminals with the new FHP series , a high-head ductable fan coil unit designed to meet the needs of installation versatility, high aeraulic performance and reduced overall dimensions. Characterised by a compact structure, a more powerful motor-ventilation unit and complete configurability, FHP represents an ideal solution for offices, commercial spaces and high-efficiency residences, where acoustic comfort and design flexibility play a key role.

High air performance thanks to the high static pressure motor-ventilation unit

The heart of the FHP series is the enhanced motor-ventilating unit , capable of reaching a useful static pressure of 50 Pa at medium speed and 60 Pa at maximum, as required by the Eurovent classification for ducted units. This feature guarantees greater adaptability to the use of plenums and ducts, offering installers the possibility of designing flexible systems even in the presence of localized resistances. The double-inlet centrifugal fans, made of antistatic ABS with wing-profile blades and staggered modules, are statically and dynamically balanced to ensure silence and reliability over time.

Structural compactness and flexible horizontal and vertical installation

Another strong point of the FHP series is its compact size: with a height of just 224 mm , the fan coil can also be installed in particularly low false ceilings or in limited technical spaces. The high-thickness galvanized steel structure, thermally and acoustically insulated with class 1 self-extinguishing panels, is equipped with a double tray for collecting condensation, making both horizontal and vertical installation possible with effective drainage in both configurations. This allows for greater design freedom even in existing buildings or in contexts of system redevelopment.

Wide range of sizes and versions for a tailor-made configuration

The FHP series consists of six models with variable air flow from 280 to 650 m³/h, available in 2 or 4-pipe configurations, with the possibility of installing an additional battery. The reversible hydraulic connections facilitate adaptation during installation. Furthermore, thanks to its innovative condensate collection tray, designed to coexist with a vertical and horizontal installation, the unit can adapt in a versatile manner to the specific needs of the space.

The flexibility of the configuration also extends to the accessories, thanks to the Galletti configurator that allows you to select control panels, valves, probes, grilles, plenums and other specific accessories, pre-configuring the unit for rapid installation. This customization significantly reduces assembly times on site, improving efficiency in integration with existing plant systems.

Acoustic optimization and consumption reduction for high-traffic environments

Thanks to the careful selection of components and the advanced design of the air circuit, the FHP series is characterized by low noise emissions , with sound power levels lower than 60 dB(A) at maximum speed. This feature makes it particularly suitable for applications in residential and public environments, such as hospitality facilities, open space offices and domestic environments where acoustic comfort is a priority.

Intelligent management, integrated sanitization and a wide choice of accessories

The FHP ducted fan coil is designed to integrate with modern control and automation systems, thanks to the availability of a wide range of electromechanical and electronic control panels. Available options include the speed switch, the EVO-2-TOUCH panel with 2.8” touch display and the My Comfort line , which also allows humidity management and water temperature monitoring.

The Bluetooth or Wi-Fi interface is optional, allowing remote control via smartphone and ensuring compatibility with advanced building automation and home automation systems. Galletti also offers a wide range of accessories, such as valves, electric resistors, grilles, plenums, fittings, motorized dampers and insulating shells, which can be pre-installed in the factory or supplied separately, ensuring quick installation and a customized configuration for each project.

Complete solution for contemporary comfort

The new FHP series confirms Galletti 's commitment to developing advanced, versatile and high-performance solutions, while ensuring high standards of Eurovent certified quality. With its compactness, high static pressure, low acoustic impact and a complete range of accessories, the FHP series represents an ideal solution for the advanced light commercial and residential market, responding to the needs of integration, energy efficiency and acoustic comfort required by modern projects.
