Climate Wizard indirect evaporative cooling Multi-cycle

The Climate Wizard range by Seeley International represents a true innovation in the field of indirect evaporative cooling, offering advanced technological solutions for commercial and industrial applications. Thanks to its patented Multi-cycle technology, these systems can cool 100% fresh outside air without adding humidity to the environment, achieving temperatures comparable to traditional air conditioning systems—while consuming up to 80% less energy.

The powerful, patented heat exchanger ensures supply air temperatures below the ambient wet bulb temperature, with a wet bulb depression of approximately 120%.

Key Benefits

One of Climate Wizard’s greatest strengths is its exceptional energy efficiency, which significantly reduces operating costs. This makes it particularly advantageous for large buildings or spaces with high heat loads. Additionally, it enhances indoor air quality by continuously supplying fresh, cooled outside air, eliminating the recirculation of stale air and contributing to occupant well-being.

From an environmental perspective, Climate Wizard is a sustainable solution, as it uses water as its only cooling element, completely eliminating the need for harmful chemical refrigerants. Unlike traditional systems, which experience energy spikes during peak hours, Climate Wizard maintains stable, efficient cooling performance—even during the hottest parts of the day—without increased energy consumption.

Flexible Integration

Climate Wizard can be used as a standalone system or integrated with existing air conditioning systems:

• Pre-cooling mode: Cooling the fresh air portion of an air handling unit (AHU), reducing its energy consumption.

• Supplementary cooling mode: Cooling the recirculated air in a DX system while still providing pre-cooled outside air.

Climate Wizard Product Range

• Climate Wizard H Series

  • Cooling capacity: Up to 40 kW

  • COP (Coefficient of Performance): Up to 19

  • Airflow: Up to 1,600 L/s (5,760 m³/h)

  • The H15 configuration can significantly reduce energy consumption when used in pre-cooling mode for air handling units or existing systems.

• Climate Wizard CW-80

  • Designed for large-scale applications, providing efficient cooling for vast spaces with minimal energy consumption.

  • Cooling capacity: Up to 214 kW

  • COP: Up to 15

  • Airflow: Up to 8,500 L/s (30,600 m³/h)

• Climate Wizard CW3

  • The most compact model, ideal for smaller spaces without compromising efficiency.

  • Cooling capacity: Up to 29 kW

  • COP: Up to 17

  • Airflow: Up to 1,300 L/s (4,680 m³/h)

Climate Wizard CW-H15

• Technology: Pure Indirect evaporative cooling – Multi-cycle

• Cooling capacity: Up to 25 kW

• Efficiency: COP/EER up to 14

• Airflow: Up to 1,100 L/s (3,960 m³/h) of fresh air

• Refrigerant: Water (R718)

• Dimensions: 2,290 x 1,825 x 1,285 mm

• Operating weight: 330 kg

Climate Wizard CW-H15S Plus

• Technology: Pure Indirect evaporative cooling – Multi-cycle + direct stage

• Cooling capacity: Up to 40 kW

• Efficiency: COP/EER up to 19

• Airflow: Up to 1,600 L/s (5,760 m³/h) of fresh air

• Refrigerant: Water (R718)

• Dimensions: 2,290 x 1,825 x 1,285 mm

• Operating weight: 345 kg

Climate Wizard CW-3

• Technology: Pure Indirect evaporative cooling – Multi-cycle + direct stage

• Cooling capacity: Up to 29 kW

• Efficiency: COP/EER up to 17

• Airflow: Up to 1,300 L/s (4,680 m³/h) of fresh air

• Refrigerant: Water (R718)

• Dimensions: 1,160 x 1,160 x 1,120 mm

• Operating weight: 210 kg

Climate Wizard CW-80

• Technology: Pure Indirect evaporative cooling – Multi-cycle

• Cooling capacity: Up to 180 kW

• Efficiency: COP/EER up to 13

• Airflow: Up to 8,500 L/s (30,600 m³/h) of fresh air

• Refrigerant: Water (R718)

• Dimensions: 3,980 x 2,550 x 3,515 mm

• Operating weight: 2,700 kg

Climate Wizard CW-80S

• Technology: Pure Indirect evaporative cooling – Multi-cycle + direct stage

• Cooling capacity: Up to 214 kW

• Efficiency: COP/EER up to 15

• Airflow: Up to 8,200 L/s (29,500 m³/h) of fresh air

• Refrigerant: Water (R718)

• Dimensions: 3,980 x 2,550 x 3,515 mm

• Operating weight: 2,850 kg

• Industrial Facilities
  Provides efficient cooling in production environments, enhancing worker comfort (and increasing productivity) while stabilizing manufacturing processes (reducing downtime).

• Warehouses
  Maintains a controlled climate in large spaces, ensuring logistical efficiency (as it operates effectively in semi-open environments) and preserving product quality.

• Storage of Pharmaceuticals and Perishable Goods
  Delivers fresh and dry air, ideal for environments requiring strict hygiene conditions and stable temperatures.

• Telecom
  Ensures the safety of transmission equipment with continuous and cost-effective cooling, without adding humidity.

• Educational Centers and Offices
  Enhances the well-being of students, teachers, and employees with fresh and healthy air while minimizing energy consumption in school buildings.

• Retail Stores and Supermarkets
  Creates a comfortable environment for customers and employees, reducing operating costs and improving existing air conditioning systems.

• Wine Cellars and Barrel Rooms
  Climate Wizard is ideal for wine preservation and barrel aging.
