FB / FE-B series by Bini Clima: hygienic fan coil with VDI 6022 certification

The units of the FB / FE-B Series by Bini Clima represent a cutting-edge solution for the air conditioning of sensitive environments, thanks to the VDI 6022 hygienic certification, which guarantees compliance with the most stringent requirements in terms of cleaning, maintenance and air quality.

Designed for vertical or horizontal installation with cabinet, these fan coils combine high performance, functional design and maximum hygiene, making them ideal for applications in hospitals, laboratories, pharmacies, schools, hotels and offices, as well as in the food industry and other public places where hygiene is a fundamental requirement.

Certified hygiene, guaranteed performance

The entire range complies with the VDI 6022 regulation, which certifies the choice of materials and construction solutions aimed at reducing microbial proliferation, simplifying cleaning and ensuring optimal resistance to detergents and disinfectants.

Among the elements that contribute to maintaining hygiene standards:

• Galvanized sheet metal structure with Armaflex Class O Plus insulation
• Condensation tray in AISI 430 stainless steel, insulated, with triple inclination and easy to inspect
• Removable and washable aluminum air filter
• Ease of inspection thanks to the fixing of the panels with threaded knobs and removable fans with wing screws

Flexible technology and high performance

The FB / FE-B Series is equipped with 5-speed AC motors or EC brushless inverter motors, equipped with electronic signal control (2-10 Vdc), for efficient, silent and modulable operation based on the needs of the environment. The proposed solutions guarantee low energy consumption and a sound pressure level lower than 48 dB(A), ensuring acoustic comfort even in particularly sensitive contexts.

The units are equipped with high efficiency water coils, with copper pipes and aluminum fins, which allow to obtain excellent performances in both cooling and heating, with air flow rates up to 805 m³/h. Configurations for 2 or 4 pipe systems are available, complete with vent valve and manual drainage.

The standard on-board control allows 3-speed management with ON/OFF function, but it is also possible to integrate thermostats on the machine or remotely, for even more precise and personalized control of environmental comfort.

Versatile and reliable terminal units

The FB / FE-B Series units are also distinguished by:

• Refined aesthetics, with painted steel grilles and RAL 9010/7047 panels
• Compact size and easy installation
• Simplified maintenance, ideal for installations in environments with high hygiene standards

Thanks to the combination of hygienic design, efficient technologies and application versatility, the FB / FE-B Series fan coils by Bini Clima represent a safe and modern choice for air conditioning projects oriented towards air quality and environmental comfort.
