“CLOCK” wall bracket

2Emme Clima CLOCK bracket is an adjustable wall bracket for outdoor condensing units, made of zinc coated steel with polyester powder finish (RAL9002). It is characterized by the new hook system that facilitates the assembling of vertical and horizontal arms and make easier the mounting process of the screw which is necessary in any case.

Clock bracket is available in not pre-mounted and pre-mounted version; in this last case the mounting screw is already inserted and the installer has only to tight the nut to guarantee the safety.


420mm dimension is tested and certified by     and it has a load capacity of 120 kg.
To obtain the certification, Clock bracket has hold up weights three times higher than declared charge (360 kg)

Clock bracket has 2 available dimensions:

Horizontal arm	Vertical arm	Sliding crossbar
420 mm	400 mm	780 mm
465 mm	400 mm	780 mm



Clock bracket is supplied with:
- Level
- Back plate spacers
- Anti-vibration feet washers
- Screws and plugs for wall fixation
- Screws kit to fix the outdoor condensing unit
- M8 self-blocking nuts (more safety) and M8 screws
